Product Name: | 311cc Four Wheel Utility Vehicle | Engine Type: | 4-stroke,Single-Cylinder, Water-cooled, Four Valve, Balance Axis |
---|---|---|---|
Transmission: | Constantly Variable Transmission | Driveline Type: | 2X4 |
Wheelbase: | 1980mm (78in) | Brakes Front: | Double A-arm Suspension |
High Light: | 4 wheel utility vehicle,recreational utility vehicle |
311cc,4-stroke,Single-Cylinder, Water-cooled, Four valve, balance axis
Engine style | 4-stroke,Single-Cylinder, Water-cooled, Four valve, balance axis | ||
Displacement | 311.4CC | ||
Horse Power | 18KW /6500rpm)25HP | ||
Max Torque | 25 N.m/5000Rpm | ||
Valve Configuration | SOHC | ||
Compression ratio | 10.0:1 | ||
Fuel Delivery System | Fuel Pump+Vacuum Diaphragm PZ 30 Carburetor | ||
Fuel capacity | 9.5L (2.1Gallon) | ||
Top speed | 75km/h | ||
Drive Type | 2X4 | ||
Drive System | Shaft-Drive | ||
Transmission | Constantly Variable Transmission | ||
Gear Selection | F-N-R | ||
Speed/Fuel meter | LED Meter | ||
Battery | 12AH 12V | ||
Rear Lights | Brake Lights & Left/Right Signal lights | ||
Ignition system | D.C.D.I | ||
Suspension Front | Double A-arm Suspension | ||
Suspension Rear | Fang power 4-Link® bar Rear Suspension | ||
Brakes F/R | 220MM F/R Dual Hydraulic Disk | ||
Front/RearTread | 1250mm ( 49.2 in) / 1150mm ( 45.2in) | ||
Front & Rear tire size | 25x8-12 / 25x10-12 | ||
Front & Rear rim size(Alloy) | 12x6 / 12x8 | ||
Warranty | 6 Months | ||
Wheelbase | 1980mm (78in) | ||
Packing size | 2290*1300*815 | ||
Ground clearance | 300mm(11.8in) | ||
Vehicle dimension (L×W×H) | 2700x1450x1760mm(106x57x69) |
Applications:
For adult use only/ Forest road/ Riverbed/Stream,
Mountain Road/ On the Beach/ Farm and Pleasure Ground
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge.
This vehicle will be sent to you assembled by sea and you can ride as soon as getting it.
The terms of payment is wire transfer,western union or moneygram.
The delivery time is about 20 days.
