Product Details:
Payment & Shipping Terms:
|
| Product Name: | 250cc Atv Quad Bike | Transmission: | 4-speed+reverse |
|---|---|---|---|
| Driving Wheel: | Rear Wheel Drive | Tires,front/rear: | 19*7-8 18*9.5-8 |
| Max Horsepower: | 11.5hp/6500r/min | Carburetor Brand: | PZ30 |
| High Light: | racing quad bikes,adult quad bikes |
||
CG 250cc Water cooled 4 stroke single cylinder Electric Start Manual Clutch 4-speed+reverse
Model:
ATV quad bike250-10
Product Description:
| Engine type : | CG,4 stroke,single cylinder |
| Engine brand : | * |
| Displacement : | 250cc |
| Cooling : | Water-cooled |
| Max horsepowe : | 11.5hp/6500r/min |
| Max torque : | 17.5n.m/5500r/min |
| Bore*stroke : | 2.6inches |
| Max speed : | 49mile/h |
| Climbing ability : | 19degree |
| Ignition : | C.D.I |
| Starting system : | Electric |
| Battery : | 12V/9Ah |
| Carburetor brand : | PZ30 |
| Engine oil : | SAE15W/40SF |
| Gear oil : | * |
| CHASSIS ETC : | |
| Clutch : | Manual |
| Transmission : | 4-speed+reverse |
| Driveline : | Chain-drive |
| Driving wheel : | Rear wheel drive |
| Suspension,front/rear : | Double a-arm/ single a-arm |
| Brakes,front/rear : | drum /Disc |
| Brake operation : | Hand+foot |
| Tires,front/rear : | 19*7-8 18*9.5-8 |
| Fuel capacity/type : | 2.9gal |
| Weight,G.W./N.W : | 440.9/352.7lbs |
| Max load : | 771.6lbs |
| DIMENSIONS : | |
| Wheelbase : | 44.9inches |
| OA L*W*H : | 57.4*33.9*37.8inches |
| Height to seat : | 29.5 inches |
| Min ground clearance : | 12.6 inches |
| Carton size : | 56.3*33.9*33.9 inches |
| Shipping info : | 66pcs/40HQ |
Applications:
1. For adult use only
2. Forest road
3. Riverbed / Stream
4. Mountain Road / Beach
5. Farm / Pleasure Ground
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or moneygram. The delivery time is about 20 days.
l Strict quality control team
Tested and checked the spare parts before on production line.
Test and check per unit before loading
l After sales service and technical assistance:
Our Company provides after sales service and technical assistance as per the customers requirement and needs.
l Delivery on time
l Warranty: One year
