35Mph Single Cylinder Chain Transmission 125cc Youth Atv

35Mph Single Cylinder Chain Transmission 125cc Youth Atv

35Mph Single Cylinder Chain Transmission 125cc Youth Atv
35Mph Single Cylinder Chain Transmission 125cc Youth Atv 35Mph Single Cylinder Chain Transmission 125cc Youth Atv 35Mph Single Cylinder Chain Transmission 125cc Youth Atv 35Mph Single Cylinder Chain Transmission 125cc Youth Atv

Large Image :  35Mph Single Cylinder Chain Transmission 125cc Youth Atv Get Best Price

Product Details:
Place of Origin: China
Brand Name: RONGYAO
Certification: EC,EEC,DOT,EPA
Model Number: youth racing atv125cc17
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Metal Frame with Carton
Delivery Time: Within 20 Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 pcs/month
Detailed Product Description
Product Name: 125cc Youth Racing Atv Engine Type: 125cc,4-stroke,single Cylinder
Max Speed: 35Mph Lubrication Type: Press/splash
Ground Clearance: 70mm Wheelbase: 1210mm
High Light:

Chain Transmission 125cc Youth Atv

,

Single Cylinder 125cc Youth Atv

,

35Mph 125cc Youth Atv

125cc 4-stroke single cylinder racing atv chain transmissioin type with two front big lamps







Model:

youth racing atv125cc17

Product Description:

 Overall length: 1735mm
Overall width: 1100mm
Overall height: 870mm
Seat height: 600mm
Max.non-limited speed: 35Mph
Ground clearance: 70mm
Wheelbase: 1210mm
Climbing angle: 20 degrees
Max.steering angle: 30 degrees
Wheels air pressure: 14Psi
Unladen mass: 130Kg
Complete vehicle kerb mass: 134Kg
Passenger #: 1
Transmission type: chain
Brakes: front/rear:disc brake by hand/foot
Tire size: 205/50-10
Fuel tank: 4.1L
Gasoline type: RQ90# or higher
Battery type: 12V6.5Ah
Lamps: two front big lamps,one rear tail lamp
Engine type: 125cc,4-stroke,single cylinder
Number of cylinders: 1
Cooling system: air cool
Spark plug valve: 0.6-0.7mm
Starting type: electric
Ignition type: C.D.I
Carburetor type: PZ20
Lubrication type: press/splash
Clutch type: auto wet-multi
Lowest fuel comsumption: ≤367g/kw.h
Lubricant type: SF15W/40 or similar
Idle speed: 1500±150 r/min
Bore x stroke: 54×54mm
Displacement: 123.6ml
Compression rate: 9.3:1
Max power: 6.1/7500(1±5%)KW/rpm
Max torque: 8.0/6000((1±5%)N.m/rpm







Applications:



1. adult use only

2. Forest road

3. Riverbed, Stream,

4 Mountain Road / Beach

5. Farm / Pleasure Ground


Terms of transaction:

Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or moneygram. The delivery time is about 20 days.




Our Service:



1. OEM Manufacturing welcome: Product, Package...
2. Sample order
3. We will reply you for your inquiry in 24 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.
