Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance

I'm Online Chat Now

Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance

China Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance supplier
Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance supplier Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance supplier Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance supplier Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance supplier

Large Image :  Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance

Product Details:

Place of Origin: China
Brand Name: RONGYAO
Certification: EC,EEC,DOT,EPA
Model Number: 70cc atv quad bike

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Metal Frame with Carton
Delivery Time: Within 20 Days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 pcs/month
Contact Now
Detailed Product Description
Product Name: 70cc Atv Quad Bike Dimension: 1300X740X835 MM
Max.Speed: ≤48 Km/h Battery: 12V/ 4AH
Max Torque: 4.51mn±500 Max.Loading: 80 KG

70CC/90CC/110CC front double swing arm,front and rear disc brake



Model:

atv quad bike70cc-2

Product Description:

Engine type FOUR STROKE,SINGLE CYLINDER
Engine brand TIANZHONG
Displacement 70/90/11cc
Cooling AIR COOLED
Max horsepower
Max torque 4.51mn±500
Bore*stroke 47mm*49.5mm
Max speed ≤48 km/h
Climbing ability >17 °
Ignition C.D.I
Starting system ELECTRIC START
Battery 12V/ 4AH
Carburetor brand
Engine oil
Gear oil
CHASSIS ETC.
Clutch AUTOMATIC
Transmission
Driveline CHAIN DRIVE
Driving wheel RR WHEEL DRIVE
Suspension,front/rear FR.DOUBLE RR.SINGLE
Brakes,front/rear DISC
Brake operation HAND
Tires,front/rear 16*8.00-6
Fuel capacity/type 2.1L
Weight,G.W./N.W 83 KG/ 72 KG
Max load 80 KG
DIMENSIONS
Wheelbase 815MM
OA L*W*H 1300X740X835 MM
Height to seat 600MM
Min ground clearance 70 MM
Carton size 1150X670X660 MM
Shipping info 40' 136T









Front Double Swing Arm 70cc ATV Quad Bike 80KG Max Loading High Performance







Terms of transaction:



Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or moneygram. The delivery time is about 20 days.
