Product Details:
Payment & Shipping Terms:
|
| Product Name: | 150cc Four Wheel Utility Vehicle | Engine Type: | 4-stroke,Single-Cylinder, Air/Oil-cooled |
|---|---|---|---|
| Fuel Delivery System: | Fuel Pump Carburetor | Driveline Type: | 2X4 |
| Forward Lights: | Headlights-High & Low Beam LED LIGHT | Brakes Front: | Front Dual Hydraulic Disk |
| High Light: | 4 wheel utility vehicle,atv utility vehicles |
||
unique design; LED light; remote control; Youth Side-By-Side Vehicle. Styled after the adult , 149.6cc 4-Stroke Engine
| ENGINE | |
| Certification | EPA approved |
| Engine type | 4-stroke,Single-Cylinder, Air/Oil-cooled |
| Displacement | 149.6cc |
| Horse Power | 7.45kw(7000r/min) 10HP |
| Valve Configuration | OHV |
| Compression ratio | 9.0:1 |
| FUEL SYSTEM | |
| Fuel Delivery System | Fuel Pump Carburetor |
| Choke System | Automatic |
| Fuel capacity | 9.5L (2.1 Gallon) |
| DRIVETRAIN | |
| Driveline Type | 2X4 |
| Final Drive | Chain-drive |
| Transmission | Constantly Variable Transmission |
| Gear Selection | Forward & Reverse Single Speed |
| ELECTRICAL SYSTEM | |
| Forward Lights | Headlights-High & Low Beam LED LIGHT |
| Rear Lights | Brake Lights & Left/Right Signal lights |
| Starting system | Electric start |
| Ignition system | C.D.I |
| SUSPENSION / BRAKES | |
| Suspension Front | Adjustable Double A-arm optional |
| Suspension Rear | Dual Shock Swing arm |
| Brakes Front | Front Dual Hydraulic Disk |
| Brakes Rear | Rear Single Axle Hydraulic Disk |
| Steering | Rock and pinion steering |
| TIRES | |
| Front Tread | 1020mm ( 40.2 in) |
| Rear Tread | 1040mm ( 38.0in) |
| Front & Rear tire size | 22x8-10 / 22x10-10 |
| MISC | |
| Loading information | 8 units/20″; 26units/40HQ |
| Top speed | 55km/h |
| Dry weight | 245kg ( 540 lbs.) |
| Gross weight | 280kgs(617lbs) |
| Wheelbase | 1860mm (71.0in) |
| Vehicle dimension (L×W×H) | 2450x1220x1397mm ( 96.5x 48.0x55.0 in) |
| Packing size | 2290x1300x815mm |
| Ground clearance | 152mm (6in) |
| Safety | Driver & Passenger Seat belts/ Driver and Passenger safety net restraints. |
Applications:
For adult use only/ Forest road/ Riverbed/Stream,
Mountain Road/ On the Beach/ Farm and Pleasure Ground
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge.
This vehicle will be sent to you assembled by sea and you can ride as soon as getting it.
The terms of payment is wire transfer,western union or moneygram.
The delivery time is about 20 days.
