Product Details:
Payment & Shipping Terms:
|
| Product Name: | 9.7kw Four Wheel Utility Vehicle | Battery Voltage: | 60V |
|---|---|---|---|
| Battery Type: | 5x Maintenance-free Battery Professional Deep Cycle GEL 12V / 100Ah | Suspension Front: | Independent McPherson Hydraulic Fluid Dampers |
| Tyres Front: | AT 24 X 8-12 | Wheelbase: | 1805mm |
| High Light: | 9.7kw Gas Utility Vehicles,1805mm Wheelbase Gas Utility Vehicles,EPA Gas Utility Vehicles |
||
Electric Utility Vehicle 9.7kw 60v 2*4 Durable Chassis Selectable TURF MODE Or LOCKED REAR DIFF
Model:
Electric Utility Vehicel01
Product Description:
| Motor | |
|---|---|
| Type | Three phase induction electric motor with copper rotor |
| Battery Voltage | 60V |
| Performance | 9.7 kW / 1950-2100 rpm |
| Battery Type | 5x maintenance-free battery Professional Deep Cycle GEL 12V / 100Ah |
| Charge Time | 8-9 am |
| Range: ECONOMY mode: | 90 km * |
| Range: POWER mode: | 85 km * |
| * Data on the roll based on the driving average speed of 30 km / h without load. | |
| Drivetrain | |
|---|---|
| Drive | 2×4 – Rear |
| Speed | Forward, neutral, reverse Electronic / 2 driving modes – POWER and ECONOMY |
| Final Drive Ratio | direct drive rear half |
| Chassis / Suspension / Brakes | |
|---|---|
| Suspension Front | Independent McPherson Hydraulic fluid dampers |
| Suspension Rear | Independent, double A-arm IRS hydraulic liquid dampers, p RUŽÍN with adjustable preload |
| Brakes Front | 2x hydraulic disc with drilled discs |
| Brakes Rear | 2x hydraulic disc with drilled discs |
| Tyres Front | AT 24 x 8-12 |
| Tyres Rear | AT 24 x 8-12 |
| Dimensions | |
|---|---|
| Length x Width x Height | 2700 mm x 1420 mm x 1870 mm |
| Wheelbase | 1805 mm |
| Seat height | 850 mm |
| Cargo Bed Dimensions | 1100 x 930 x 235 mm |
| Operating weight | 442 kg |
| Total payload | 534 kg (driver + passenger + cargo in the back) |
| Other | |
|---|---|
| Display | Digital multifunction display features: Speedometer Odometer Mileage counter reading Board clocks |
| Lights | Direction indicators, main beam LED headlights, LED tail / brake lights |
| Warranty | |
|---|---|
| 12 months up to 24 months* | * If 1 month and 6 months services have been done by a Licensed Mechanic – warranty is extended to 2 years. Please make sure you have proof of services. |
Applications:
For adult use only, Forest road, Riverbed, Stream,
Mountain Road, On the Beach, Farm and Pleasure Ground
Terms of transaction:
We have EPT and DOT certificate and you can buy this UTV in our company. We will help you to do customs clearance when it arrives and you will get it safely.
| 1. For the sample: we can delivery the sample at the first order. but need add some sample fee to balance the export cost in Chinese custom. |
| 2. The UTV COLOR can choose by yourself on the ordinary colors,Also can do the custom-made |
| 3. Shipping:General by the sea shipping, port to port. can't do the door to door. |
| 4. The Package: The bike have been 90% assembled, with the accessory kit can be do rapid |
| assembly. Don't need professional tools and mechanic. |
| 5. Delivery: we have no stock, all of these UTV is production by the order, Just for one order, the production time general will take about 15-20days. |
| 6. If for the EEC Model, can delivery the COC certificate for you registration, Also can delivery the Certificate Of Origin(CO). |
| 7. Warranty: Engine and the Frame is one year, the other if not Artificial damage is 5 months. The spare parts also can order from us. |
