Product Details:
Payment & Shipping Terms:
|
| Product Name: | 150cc Four Wheel Utility Vehicle | Transmission: | Constantly Variable Transmission |
|---|---|---|---|
| Suspension,front/rear: | Adjustable Double A-arm Optional | Brakes,front/rear: | Front Dual Hydraulic Disk |
| Wheelbase: | 1860mm | Top Speed: | 55km/h |
| High Light: | 4 wheel utility vehicle,recreational utility vehicle |
||
150cc 4-stroke Single-Cylinder Air/Oil-cooled 21x7-10/22x10-10 aluminum rim
Model:
sports utility vehicle150-6
Product Description:
| Engine type | 4-stroke,Single-Cylinder, Air/Oil-cooled |
| Displacement | 149.6cc |
| Horse Power | 7.45kw(7000r/min) 10HP |
| Valve Configuration | OHV |
| Compression ratio | 9.0:1 |
| FUEL SYSTEM | |
| Fuel Delivery System | Fuel Pump Carburetor |
| Choke System | Automatic |
| Fuel capacity | 9.5L (2.1 Gallon) |
| DRIVETRAIN | |
| Driveline Type | 2X4 |
| Final Drive | Chain-drive |
| Transmission | Constantly Variable Transmission |
| Gear Selection | Forward & Reverse Single Speed |
| ELECTRICAL SYSTEM | |
| Forward Lights | Headlights-High & Low Beam LED LIGHT |
| Rear Lights | Brake Lights & Left/Right Signal lights |
| Starting system | Electric start |
| Ignition system | C.D.I |
| SUSPENSION / BRAKES | |
| Suspension Front | Adjustable Double A-arm optional |
| Suspension Rear | Dual Shock Swing arm |
| Brakes Front | Front Dual Hydraulic Disk |
| Brakes Rear | Rear Single Axle Hydraulic Disk |
| Steering | Rock and pinion steering |
| TIRES | |
| Front Tread | 1020mm ( 40.2 in) |
| Rear Tread | 1040mm ( 38.0in) |
| Front & Rear tire size | 21x7-10/22x10-10 |
| MISC | |
| Loading information | 8 units/20″; 26units/40HQ |
| Top speed | 55km/h |
| Dry weight | 245kg ( 540 lbs.) |
| Gross weight | 280kgs(617lbs) |
| Wheelbase | 1860mm (71.0in) |
| Vehicle dimension (L×W×H) | 2450x1220x1397mm ( 96.5x 48.0x55.0 in) |
| Packing size | 2290x1300x815mm |
| Ground clearance | 152mm (6in) |
| Safety | Driver & Passenger Seat belts/ Driver and Passenger safety net restraints. |
Applications:
For adult use only, Forest road, Riverbed, Stream,
Mountain Road, On the Beach, Farm and Pleasure Ground
Terms of transaction:
We have EPT and DOT certificate and you can buy this UTV in our company. We will help you to do customs clearance when it arrives and you will get it safely.
| 1. For the sample: we can delivery the sample at the first order. but need add some sample fee to balance the export cost in Chinese custom. |
| 2. The UTV COLOR can choose by yourself on the ordinary colors,Also can do the custom-made |
| 3. Shipping:General by the sea shipping, port to port. can't do the door to door. |
| 4. The Package: The bike have been 90% assembled, with the accessory kit can be do rapid |
| assembly. Don't need professional tools and mechanic. |
| 5. Delivery: we have no stock, all of these UTV is production by the order, Just for one order, the production time general will take about 15-20days. |
| 6. If for the EEC Model, can delivery the COC certificate for you registration, Also can delivery the Certificate Of Origin(CO). |
| 7. Warranty: Engine and the Frame is one year, the other if not Artificial damage is 5 months. The spare parts also can order from us. |
