Product Details:
Payment & Shipping Terms:
|
| Product Name: | 500cc 4 Wheel Utility Vehicle | Starter: | Electric And Recoil Starter |
|---|---|---|---|
| Transmission/Final Drive: | C.V.T Automatic Clutch (R/N/L/H) | Front Tires: | Front 25×8.00-12 Rear 25×10.00-12 |
| Wheels: | Steel | Ground Clearance(mm): | 210 MM |
| High Light: | 4 wheel utility vehicle,recreational utility vehicle |
||
500CC,CF188,4x4/2x4 switchable,Four-stroke cycle,single-cylinder,shaft drive transission,water cooled
Model:
sports utility vehicle500-7
Product Description:
| Engine type | CF188,Four-stroke cycle,single-cylinder,shaft drive transission,water cooled | |
| Engine brand | CFMOTO | |
| Displacement | 493 cc | |
| Cooling | Water cooled | |
| Max horsepower | 32HP,24 KW | |
| Max torque | 38.8N·m/5500r/min | |
| Bore*stroke | 87.5 x 82mm(3.44x3.23in) | |
| Max speed | 50m/h,80km/h | |
| Climbing ability | >30° | |
| Ignition | C.D.I | |
| Starter | electric and recoil starter | |
| Battery | 12V/ 36AH | |
| Carburetor brand | MIKUNI | |
| Engine oil | SAE 15W—40/SF | |
| Gear oil | ||
| CHASSIS ETC. | ||
| Clutch | Automatic | |
| Transmission | C.V.T Automatic clutch (R/N/L/H) | |
| Driveline | shaft | |
| Driving wheel | 2x4 & 4x4 switchable | |
| Suspension,front/rear | 4-wheel independent suspension | |
| Brakes,front/rear | Front disc, rear disc | |
| Brake operation | foot brake | |
| Tires,front/rear | Front 25×8.00-12 Rear 25×10.00-12 | |
| Fuel capacity/type | 22L | |
| Weight,G.W./N.W. | 630 KG/680KG | |
| Max load | 300 KG | |
| DIMENSIONS | ||
| Wheelbase | 1730 MM | |
| OA L*W*H | 2600×1280×1960 MM | |
| Height to seat | 890 MM | |
| Min ground clearance | 210 MM | |
| Carton size | 2.32 X 1.31 X 1.27 MM | |
| Shipping info | 8UNITS | |
Applications:
For adult use only, Forest road, Riverbed, Stream,
Mountain Road, On the Beach, Farm and Pleasure Ground
Shipping and Payment terms:
1. Shipping: by express, by air or by sea according to your order quantity.
2. Payment Terms: 30% T/T,western union or moneygram as deposit while placing order and the balance payment would be settled before order shipment
3. 100% prepaid is requested on order payment amount less than USD2,000
About us:
Our growing circle of wholesale dealers includes customers from Europe, U.S.A, Africa, Canada and South America. Our main goal is to manufacture top quality products with emphasis on safety and packing security out of concern to the front end customers who buy from our dealers. Our staffs are in the factories 24 hours a day constantly checking and improving the quality. Loyalty is highly important to us especially when it concerns to safety. (Our dealers customers will return to you and your business will make great profit. )
FAQ:
1. Q: Can I mix different models in one container?
A: Yes, different models can be mixed in one container.
2. Q: How does your factory do regarding quality control?
A: Quality is priority. our staff always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.
3. Q:What's your warranty terms?
A: for engine and frame is one year,and other parts are 3 months.
4. Q: Will you deliver the right goods as ordered? How can I trust you?
A: Yes, we will. The core of our company culture is honesty and credit. Our company is the member of ecer.com . If you check with ecer, you will see that we have never got any complaint from our customers.
Contact Person: Jackycai
Tel: 0086-13761175834
