Product Details:
Payment & Shipping Terms:
|
| Product Name: | 150cc Atv Quad Bike | Starting System: | ELECTRIC+FOOT |
|---|---|---|---|
| Min Ground Clearance: | 110mm | Seat Height: | 830mm |
| Dimension(LxWxH): | 1679X998X1094mm | Max Power: | 5.5kW/7000(r/min) |
| High Light: | off road quad bikes,adult quad bikes |
||
150CC,Air cooled,8" TIRE,FRONT DRUM BRAKE, REAR DISC BRAKE,FRONT AIR SHOCH
Model:
atv quad bike150-10
Product Description:
| Engine type | 150CC,4 STROCK,AIR COOLED,SINGLE CYLINDER,CVT) |
| Engine brand | JL |
| Displacement | 150CC |
| Cooling | AIR COOLED |
| Max horsepower | 5.5kW/7000(r/min) |
| Max torque | 10.5N•m/6000(r/min) |
| Bore*stroke | 57.4X57.8 (mm) |
| Max speed | 55㎞/h |
| Climbing ability | 35 |
| Ignition | C.D.I |
| Starting system | ELECTRIC+FOOT |
| Battery | 12V9Ah |
| Carburetor brand | KF(PZ30BL) |
| Engine oil | SAE-15W/40 |
| Gear oil | |
| CHASSIS ETC. | |
| Clutch | CVT |
| Transmission | 1-forward,1-neutral,1-reverse |
| Driveline | CHAIN |
| Driving wheel | , |
| Suspension,front/rear | FRONT DOUBLE A-ARM |
| Brakes,front/rear | FRONT DRUM/REAR DISC |
| Brake operation | FRONT:HANDLE/REAR:FOOT |
| Tires,front/rear | 19X7.0-8/18X9.50-8 |
| Fuel capacity/type | 4.5L |
| Weight,G.W./N.W. | 400.4LBS/343.2LBS |
| Max load | 330 LBS |
| DIMENSIONS | |
| Wheelbase | 1150mm |
| OA L*W*H | 1679X998X1094mm |
| Height to seat | 830mm |
| Min ground clearance | 110mm |
| Carton size | 64.9”x44”x33.8” |
| Shipping info | 42PCS/40HQ |
Feature:
ATV is the abbreviation of All Terrain Vehicle.
ATV tires is wide, increases the contact area with the ground, resulting in a strong friction, make it not easy to skid. ATV for actual transportation operations, hills/forest farm/mining area, etc.
Payment:
T/T,Western Union and Moneygram.
(30% is the deposit, and 70% must be paid before delivery)
Terms of transaction:
Our warranty is 1 years. If your vehicle is broken,the spare parts will be sent to you free of charge. This vehicle will be sent to you assembled by sea and you can ride as soon as getting it. The terms of payment is wire transfer,western union or moneygram. The delivery time is about 20 days.
1. What is the delivery time?
15-20 days after receipt of your payment.
2. What is your payment term ?
T/T by bank transfer, Moneygram or Western union.
3.What is your warranty terms?
| Engine & Frame: | quality guarantee period is 1 year or 5000km |
| Atv parts: | 3 to 6 months |
NOTE: Parts urgent by air, normally warranty parts or parts order with container.
4. What is the minimum order quantity?
We accept the sample order for testing.
All-terrain vehicle (ATV), also known as a quad, quad bike, three-wheeler, four-wheeler, or quadricycle as defined by the American National Standards Institute (ANSI) is a vehicle that travels on low-pressure tires, with a seat that is straddled by the operator, along with handlebars for steering control. As the name implies, it is designed to handle a wider variety of terrain than most other vehicles.
